Description
Frigidaire 30-inch freestanding electric range features 5 cooktop elements, Even Baking technology, SpaceWise® dual expandable element and a total oven capacity of 5.3 cu. ft.
Features
QUICK BOIL ELEMENT (3,000W)
Get meals to the table faster with the powerful 3,000W Quick Boil element.
FLEXIBLE FIVE ELEMENT COOKTOP.
Experience ultimate cooking flexibility with a cooktop that has five elements designed to handle all of your cooking needs.
EVEN BAKING TECHNOLOGY
This latest technology ensures even baking every time.
SPACEWISE® DUAL EXPANDABLE ELEMENT (6"/9")
Our convenient 2-in-1 element expands from 6" for smaller pots to 9" for larger cookware, providing more cooktop flexibility.
EXTRA WIDE STORE-MORE™ STORAGE DRAWER
Our redesigned Store-More™ Storage drawer is now even wider - allowing you to store any unused oven racks or baking trays.
Specifications
General
Fuel Type
Electric
Installation Type
Freestanding
Color
White
Manufacturer Color
White
Cooktop
Burners/Elements
5
Burners/Elements Output
• Right Front Element: 3000 Watts
• Right Rear Element: 1200 Watts
• Left Front Element (Small): 1400 Watts
• Left Front Element (Large): 3000 Watts
• Left Rear Element: 1200 Watts
• Center Rear Element: 100 Watts
• Right Rear Element: 1200 Watts
• Left Front Element (Small): 1400 Watts
• Left Front Element (Large): 3000 Watts
• Left Rear Element: 1200 Watts
• Center Rear Element: 100 Watts
Burner/Element Size
• Right Front Element Size: 9"
• Right Rear Element Size: 6"
• Left Front Element Size (Small): 6"
• Left Front Element Size (Large): 9"
• Left Rear Element Size: 6"
• Right Rear Element Size: 6"
• Left Front Element Size (Small): 6"
• Left Front Element Size (Large): 9"
• Left Rear Element Size: 6"
Elements
Smoothtop
Oven
Capacity (cu. ft.)
5.3 cu. ft.
Number of Ovens
Single
Programs
• Bake
• Broil
• Preheat
• Broil
• Preheat
Features
Technologies
• Even Baking Technology
• SpaceWise® Dual Expandable Element
• SpaceWise® Dual Expandable Element
Digital Temperature Display
Yes
Oven Light
Yes
Additional Information
• Hot-Surface Indicator Light
• Element On Indicator Light
• Kitchen Timer
• Bake Element: 2600 Watts
• Bake Element Pass: 4
• Bake Element Type: Raised
• Broil Element: 3000 Watts
• Broil Element Pass: 4
• 6 Rack Positions
• Oven Interior Color: Midnight Black
• Oven Light Type: Halogen
• Adjustable Leveling Legs
• Element On Indicator Light
• Kitchen Timer
• Bake Element: 2600 Watts
• Bake Element Pass: 4
• Bake Element Type: Raised
• Broil Element: 3000 Watts
• Broil Element Pass: 4
• 6 Rack Positions
• Oven Interior Color: Midnight Black
• Oven Light Type: Halogen
• Adjustable Leveling Legs
Drawer Features
Storage
Yes
Electrical Information
Information
• Connected Load @ 240V: 12 kW
• Minimum Circuit Required: 40 Amps
• Voltage Rating: 240 V
• Minimum Circuit Required: 40 Amps
• Voltage Rating: 240 V
Certifications and Approvals
Information
UL
Dimensions
Class Width
30"
Width
30 inch(es) / 76.2 cm
Height
46.75 inch(es) / 118.75 cm
Depth (Without Handles)
26 inch(es) / 66.04 cm
Depth (Including Handles)
28.5 inch(es) / 72.39 cm
Additional Dimensions
• Depth With Door 90° Open: 47 5/16"
• Maximum Height: 47 3/4"
• Oven Interior Height: 8 1/8"
• Oven Interior Width: 25 3/16"
• Oven Interior Depth: 19 7/8"
• Maximum Height: 47 3/4"
• Oven Interior Height: 8 1/8"
• Oven Interior Width: 25 3/16"
• Oven Interior Depth: 19 7/8"
Warranty
Warranty
1 Year Parts and Labor
UPC
UPC#
12505514616
